Impromptu - Classical Music Discovery Chatbot

Chatbot intended to help users discover classical music.

Embabel features:

Agent-based chatbot with RAG (Neo4j vector storage)
DICE proposition extraction pipeline for memories about users
Spotify integration for playlist management

Overview

Impromptu is a conversational AI assistant for classical music discovery, powered by the Embabel Agent Framework. It combines RAG-based knowledge retrieval, multi-platform music integration, and semantic memory extraction to create a personalized music exploration experience.

Login	Chat Interface

Key Capabilities:

Natural language conversations about classical music with RAG-enhanced responses
Integration with Spotify (playlists, playback) and YouTube (video search, playback)
Access to IMSLP (600,000+ public domain scores) and Met Museum art collections
Automatic extraction and recall of user preferences and interests via DICE memory
Dynamic concert program and listening guide generation

Architecture

Impromptu is built on the Embabel Agent Framework (documentation) using three architectural pillars: Utility AI for flexible tool orchestration, Matryoshka Tools for progressive disclosure of capabilities, and DICE Memory for semantic knowledge extraction.

graph TB
    subgraph User Layer
        UI[Vaadin Chat UI]
    end

    subgraph Chat Layer
        CA[ChatActions]
        CB[Utility Chatbot]
    end

    subgraph Tool Layer
        MT[Matryoshka Tools]
        AT[Agentic Tools]
        RAG[RAG Search]
    end

    subgraph Memory Layer
        DICE[DICE Extraction]
        PR[Proposition Repository]
    end

    subgraph Persistence
        NEO[(Neo4j Graph + Vector)]
    end

    UI --> CA
    CA --> CB
    CB --> MT
    CB --> AT
    CB --> RAG
    CA --> DICE
    DICE --> PR
    PR --> NEO
    RAG --> NEO

Utility AI Chatbot

The chatbot uses the Utility AI pattern from the Embabel Agent Framework, where the LLM autonomously selects which tools to invoke based on user intent. Unlike scripted chatbots, the LLM reasons about the best approach for each query.

sequenceDiagram
    participant U as User
    participant C as ChatActions
    participant L as LLM
    participant T as Tools
    participant M as Memory

    U->>C: "Find me a good recording of Brahms Symphony 4"
    C->>M: Load recent propositions (top 10)
    C->>L: Send message + tools + memory context

    Note over L: LLM reasons about approach

    L->>T: Call spotify.searchTracks("Brahms Symphony 4")
    T-->>L: Track results with performers
    L->>T: Call performanceFinder("Brahms Symphony 4")
    T-->>L: Structured Performance objects

    L-->>C: Response with recommendations
    C-->>U: Display response
    C->>M: Async: Extract propositions

Implementation: The AgentProcessChatbot.utilityFromPlatform() creates a chatbot that discovers all @Action methods and makes them available as tools. The LLM decides when to use RAG search, query the database, or call external APIs.

@Bean
Chatbot chatbot(AgentPlatform agentPlatform) {
    return AgentProcessChatbot.utilityFromPlatform(agentPlatform);
}

Matryoshka Tools

Matryoshka Tools implement progressive disclosure: the LLM initially sees only high-level "facade" tools. When invoked, these reveal specific sub-tools. This reduces cognitive load while maintaining full capability.

graph LR
    subgraph "Initial View (4 tools)"
        S[spotify]
        I[imslp]
        M[metmuseum]
        Y[youtube]
    end

    subgraph "After spotify invoked"
        S1[searchTracks]
        S2[getPlaylists]
        S3[createPlaylist]
        S4[addToPlaylist]
        S5[getPlaybackState]
    end

    subgraph "After imslp invoked"
        I1[findScores]
        I2[searchWorks]
        I3[browseByComposer]
    end

    S -.->|reveals| S1
    S -.->|reveals| S2
    S -.->|reveals| S3
    S -.->|reveals| S4
    S -.->|reveals| S5

    I -.->|reveals| I1
    I -.->|reveals| I2
    I -.->|reveals| I3

Available Tool Facades:

Facade	Purpose	Sub-tools
`spotify`	Music playback & playlists	searchTracks, getPlaylists, createPlaylist, addToPlaylist, play, pause
`imslp`	Public domain scores	findScores, searchWorks, browseByComposer
`metmuseum`	Art collection	searchArtworks, getArtwork, browseByDepartment
`youtube`	Video search & playback	searchVideos, playVideo
`pdf`	Document generation	generateDocument (programs, guides, biographies)

Implementation: Tools use the @MatryoshkaTools annotation:

@MatryoshkaTools(name = "spotify", description = "Access Spotify music features")
public class SpotifyTools {
    @Tool(description = "Search for tracks")
    public List<TrackInfo> searchTracks(String query) { ... }

    @Tool(description = "Get user's playlists")
    public List<PlaylistInfo> getPlaylists() { ... }
}

Agentic Cypher Query Generation

The CypherQueryTools component (from the embabel-agent-rag-neo-drivine module) is an agentic tool that uses an LLM to dynamically generate Cypher queries from natural language. Unlike simple API wrappers, this tool invokes an LLM internally to translate user questions into valid database queries. Critically, query generation is constrained by the domain schema (DataDictionary), ensuring queries are both safe and valid.

flowchart LR
    subgraph "Domain Schema (DataDictionary)"
        S[Schema Definition]
        E1["Composer
        - completeName
        - birthYear, deathYear
        - popular, recommended"]
        E2["Work
        - title, subtitle
        - searchTerms
        - popular, recommended"]
        E3["Performer
        - name, instrument"]
        R["Relationships
        COMPOSED, OF_GENRE
        OF_EPOCH, PERFORMED"]
    end

    subgraph "CypherQueryTools"
        LLM[LLM Query Generator]
        V[Schema Validator]
        PM[Persistence Manager]
    end

    subgraph "Safety Guarantees"
        G1[Only known labels]
        G2[Only defined properties]
        G3[Read-only queries]
        G4[Valid relationships]
    end

    S --> E1
    S --> E2
    S --> E3
    S --> R

    E1 --> LLM
    E2 --> LLM
    E3 --> LLM
    R --> LLM

    LLM --> V
    V --> G1
    V --> G2
    V --> G3
    V --> G4
    V --> PM

Why Schema Matters:

The schema serves as a contract between the domain model and the LLM. Without it, the LLM might generate queries that:

Reference non-existent node labels or properties
Attempt to create or modify data (injection attacks)
Use incorrect relationship types
Return unexpected data structures

By providing the schema to the LLM, it can generate valid queries like:

// "Who composed the most violin concertos?"
MATCH (c:Composer)-[:COMPOSED]->(w:Work)
WHERE w.title CONTAINS 'Violin Concerto'
RETURN c.completeName, count(w) as concertos
ORDER BY concertos DESC
LIMIT 10

Schema Definition:

@Bean
DataDictionary musicSchema() {
    return DataDictionary.fromClasses(
        "art_music",
        Composer.class,      // Node label with properties
        Work.class,          // Linked via COMPOSED relationship
        Performer.class,     // Artist/musician entities
        MusicPlace.class,    // Venues, cities
        ImpromptuUser.class  // User preferences
    );
}

Entity classes define the schema through annotations:

@CreationPermitted(false)  // LLM cannot create new composers
public interface Composer extends NamedEntity {
    String getCompleteName();
    Long getBirthYear();
    Long getDeathYear();

    @Relationship(name = "COMPOSED")
    List<Work> getWorks();
}

Tool Usage:

cypherQueryTools.tool("""
    Use this tool to query existing entities such as composers and works.
    If you are asked questions like "Who composed the most violin concertos?" or
    "List saxophone concertos" use this tool
    """)

The schema-constrained approach enables powerful natural language queries while preventing the LLM from generating unsafe or invalid database operations.

Graph Exploration and Visualization

The agentic Cypher tool can discover complex relationships across the knowledge graph. For example, finding string quartets composed by those who influenced a particular composer:

// String quartets by Messiaen's influencers
MATCH (influencer:Composer)-[i:INFLUENCED]->(messiaen:Composer {id: 'olivier-messiaen-1908'})
MATCH (influencer)-[c:COMPOSED]->(w:Work)-[sf:SCORED_FOR]->(sq:Ensemble {id: 'string-quartet'})
RETURN influencer, c, w, sf, sq

This query returns graph elements that can be visualized directly in Neo4j Browser or web-based graph libraries:

The graph shows composers who influenced Olivier Messiaen, connected to their string quartet compositions. Each node represents an entity (composer, work, or ensemble) and edges show the relationships between them.

Note: Olivier Messiaen (1908–1992) is widely regarded as one of the most important composers who lived wholly in the 20th century. His unique musical language combined complex rhythms, modes of limited transposition, birdsong transcriptions, and deeply spiritual Catholic mysticism.

Listen to his monumental Turangalîla-Symphonie

The influence relationships shown here are LLM-generated through the Composer Enhancement Pipeline and reviewed by musicologists before being committed to the knowledge graph. The SCORED_FOR relationships linking works to ensembles and instruments are inferred from work titles using pattern matching. Both datasets will continue to be refined and expanded over time.

The agentic tool can answer natural language questions like "Which composers influenced Messiaen and wrote string quartets?" by composing the appropriate Cypher query, executing it, and returning structured results suitable for both textual responses and graph visualization.

Agentic Tools for Performance Discovery

Agentic Tools go beyond simple API calls - they orchestrate multi-step LLM-driven workflows. The Performance Finder demonstrates this: it searches across platforms, parses metadata, and structures results into coherent Performance objects.

flowchart TB
    subgraph "Agentic Tool: Performance Finder"
        direction TB
        Q[User Query: Find Brahms 4 recording]

        subgraph "LLM Orchestration"
            A[Analyze query intent]
            B[Search Spotify tracks]
            C[Search YouTube videos]
            D[Parse performer metadata]
            E[Group into performances]
            F[Return structured results]
        end

        Q --> A
        A --> B
        A --> C
        B --> D
        C --> D
        D --> E
        E --> F
    end

    subgraph "Output: Performance Objects"
        P1["Performance 1
        Performer: Kleiber
        Ensemble: Vienna Phil
        Source: spotify
        Tracks: [Mov I, II, III, IV]"]

        P2["Performance 2
        Performer: Bernstein
        Ensemble: NY Phil
        Source: youtube
        Video: Full concert"]
    end

    F --> P1
    F --> P2

Performance Model:

interface Performance<T extends Playable> extends Playable, NamedEntity {
    String workId();      // Links to domain Work entity
    String performer();   // Soloist or lead musician
    String ensemble();    // Orchestra/quartet (nullable)
    String conductor();   // Nullable
    String albumName();
    String source();      // "spotify" or "youtube"
    List<T> tracks();     // Individual movements or videos
}

The LLM is guided by a system prompt to parse performer/conductor/ensemble from track metadata, distinguish individual movements (I, II, III, IV), and return properly structured objects.

DICE Proposition Memory

DICE (Domain-Integrated Context Engineering) extracts semantic propositions from conversations, building a persistent knowledge graph about users, their preferences, and musical entities.

flowchart LR
    subgraph "Conversation"
        M1["User: I love Brahms, especially
        his chamber music"]
        M2["Assistant: Brahms wrote some
        of the finest chamber works..."]
    end

    subgraph "Extraction Pipeline"
        E[LLM Extractor]
        R[Reviser]
        ER[Entity Resolver]
    end

    subgraph "Propositions"
        P1["User loves Brahms
        confidence: 0.95"]
        P2["User interested in chamber music
        confidence: 0.90"]
    end

    subgraph "Graph Projection"
        G["(User)-[:LOVES]->(Brahms)
        (User)-[:INTERESTED_IN]->(Chamber Music)"]
    end

    M1 --> E
    M2 --> E
    E --> R
    R --> ER
    ER --> P1
    ER --> P2
    P1 --> G
    P2 --> G

Extraction Flow:

Event-Driven: After each chat response, ConversationAnalysisRequestEvent triggers async extraction
Incremental Analysis: Windowed processing with deduplication prevents redundant extraction
Entity Resolution: Hierarchical resolver minimizes LLM calls:
- EXACT_MATCH → HEURISTIC_MATCH → EMBEDDING_MATCH → LLM_VERIFICATION → LLM_BAKEOFF
Graph Projection: Propositions become semantic relationships in Neo4j

Domain Schema:

// Entity types
@Entity class Composer extends NamedEntity { ... }
@Entity class Work extends NamedEntity { ... }
@Entity class Performer extends NamedEntity { ... }
@Entity class ImpromptuUser extends NamedEntity { ... }

// Relationship types
enum RelationType { LOVES, LIKES, DISLIKES, KNOWS, INTERESTED_IN, COMPOSED, PERFORMED }

Memory Recall: During chat, the most relevant propositions are loaded as context:

var memory = Memory.forContext(user.currentContext())
    .withRepository(propositionRepository)
    .withEagerQuery(q -> q.orderedByEffectiveConfidence().withLimit(10))
    .withProjector(memoryProjector);

Neo4j Persistence Layer

Neo4j serves as both the vector store for RAG and the graph database for propositions and domain entities, using the embabel-agent-rag-neo-drivine module. This dual role enables semantic search and relationship-based queries.

graph TB
    subgraph "Vector Store (RAG)"
        D[Documents]
        C[Chunks with Embeddings]
        VS[Vector Similarity Search]
    end

    subgraph "Graph Store (Domain)"
        CO[Composer Nodes]
        W[Work Nodes]
        P[Performer Nodes]
        U[User Nodes]
    end

    subgraph "Proposition Store"
        PR[Proposition Nodes]
        EM[Entity Mentions]
        REL[Semantic Relationships]
    end

    D --> C
    C --> VS

    CO -->|COMPOSED| W
    P -->|PERFORMED| W
    U -->|LOVES| CO
    U -->|INTERESTED_IN| W

    PR --> EM
    EM --> CO
    EM --> W
    EM --> U
    PR --> REL

Key Repositories:

Repository	Purpose
`PropositionRepository`	CRUD + vector search for propositions
`NamedEntityDataRepository`	Domain entities (Composer, Work, etc.)
`SearchOperations`	RAG chunk retrieval with similarity search

Proposition Query Capabilities:

propositionRepository.query(PropositionQuery.builder()
    .contextId(user.getContextId())
    .status(PropositionStatus.ACTIVE)
    .minConfidence(0.7)
    .orderedByEffectiveConfidence()  // Includes time decay
    .withLimit(10)
    .build());

Effective Confidence: Propositions decay over time using exponential decay:

effectiveConfidence = confidence × exp(-k × daysSinceRevision / 365)

This ensures recent interactions are weighted more heavily while preserving long-term knowledge.

Reference Data Model

The application maintains a rich graph of classical music reference data. This data is loaded from Open Opus and enhanced via the Composer Enhancement Pipeline.

graph LR
    subgraph "Core Entities"
        C[Composer]
        W[Work]
    end

    subgraph "Classification"
        E[Epoch]
        G[Genre]
        N[Nationality]
    end

    subgraph "Instrumentation"
        ENS[Ensemble]
        I[Instrument]
        F[Family]
    end

    subgraph "Musicology"
        T[Technique]
        C2[Composer]
    end

    C -->|COMPOSED| W
    C -->|OF_EPOCH| E
    C -->|HAS_NATIONALITY| N
    C -->|USES| T
    C -->|INFLUENCED| C2

    W -->|OF_GENRE| G
    W -->|SCORED_FOR| ENS
    W -->|SCORED_FOR| I
    W -->|FEATURES| I

    ENS -->|CONTAINS| I
    I -->|OF_FAMILY| F

Entity Descriptions:

Entity	Description	Example
Composer	A musical composer	Johannes Brahms
Work	A musical composition	Symphony No. 4 in E minor
Epoch	Historical period	Romantic, Baroque, Modern
Genre	Musical form/category	Orchestral, Chamber, Keyboard
Nationality	Composer's nationality	German, Austrian, French
Technique	Compositional technique	Counterpoint, Serialism, Minimalism
Ensemble	Performing group type	Symphony Orchestra, String Quartet
Instrument	Musical instrument	Violin, Piano, French Horn
Family	Instrument family	Strings, Woodwinds, Brass

Relationship Descriptions:

Relationship	Description
`COMPOSED`	Links composer to their works
`OF_EPOCH`	Classifies composer by historical period
`OF_GENRE`	Classifies work by musical genre
`HAS_NATIONALITY`	Composer's national identity
`INFLUENCED`	Musical influence between composers
`USES`	Techniques employed by a composer
`SCORED_FOR`	Instruments/ensembles a work requires
`FEATURES`	Featured solo instruments (concertos)
`CONTAINS`	Instruments that make up an ensemble
`OF_FAMILY`	Instrument's family classification

Getting Started

Prerequisites

Java: Java 21+ is required.

Docker: Required for running Neo4j and MCP tool containers.

Environment Variables

The application uses environment variables for API keys and configuration. Create a .env file or export these variables before running.

Required

Variable	Description	Source
`OPENAI_API_KEY`	OpenAI API key for LLM, TTS, and embeddings	platform.openai.com
`GOOGLE_CLIENT_ID`	Google OAuth2 client ID	console.cloud.google.com
`GOOGLE_CLIENT_SECRET`	Google OAuth2 client secret	Same as above

Optional Integrations

Variable	Description	Source
`SPOTIFY_CLIENT_ID`	Spotify app client ID for playlist management	developer.spotify.com
`SPOTIFY_CLIENT_SECRET`	Spotify app client secret	Same as above
`YOUTUBE_API_KEY`	YouTube Data API v3 key for video search	console.cloud.google.com (enable YouTube Data API v3)
`BRAVE_API_KEY`	Brave Search API key for web search MCP	brave.com/search/api

Neo4j (optional - defaults provided for local development)

Variable	Default	Description
`NEO4J_HOST`	`localhost`	Neo4j server hostname
`NEO4J_PORT`	`7888`	Neo4j Bolt port
`NEO4J_USERNAME`	`neo4j`	Database username
`NEO4J_PASSWORD`	`brahmsian`	Database password
`NEO4J_DATABASE`	`neo4j`	Database name
`NEO4J_HTTP_PORT`	`8889`	Neo4j Browser HTTP port

Example .env file:

# Required
export OPENAI_API_KEY=sk-...
export GOOGLE_CLIENT_ID=your-client-id.apps.googleusercontent.com
export GOOGLE_CLIENT_SECRET=your-client-secret

# Optional integrations
export SPOTIFY_CLIENT_ID=your-spotify-client-id
export SPOTIFY_CLIENT_SECRET=your-spotify-client-secret
export YOUTUBE_API_KEY=your-youtube-api-key
export BRAVE_API_KEY=your-brave-api-key

Starting Neo4j

The application uses Neo4j as its vector store for RAG. Start it with Docker Compose:

docker compose up -d

This starts Neo4j with:

Bolt port: 7888 (for application connections)
HTTP port: 8889 (for Neo4j Browser at http://localhost:8889)
Credentials: neo4j / brahmsian

To stop Neo4j:

docker compose down

To wipe all data and start fresh, delete the volume in docker compose down as follows:

docker compose down -v

Backing Up and Restoring the Database

Backup (requires stopping Neo4j):

docker stop impromptu-neo4j
docker run --rm -v impromptu_neo4j_data:/data -v $(pwd):/backup alpine tar cvf /backup/neo4j-backup.tar /data
docker start impromptu-neo4j

Restore from backup:

docker stop impromptu-neo4j
docker run --rm -v impromptu_neo4j_data:/data -v $(pwd):/backup alpine sh -c "cd /data && tar xvf /backup/neo4j-backup.tar --strip 1"
docker start impromptu-neo4j

Export to CSV: Use the "Export Cypher" button in the Impromptu panel's Influences tab to export all Reference nodes (Composers, Works, Epochs, Genres) and relationships to CSV files in data/exports/. This also generates import_references.cypher for fast bulk loading.

Load reference data (e.g., to populate a fresh database):

# Use the load script (copies CSVs to Neo4j, uses LOAD CSV for fast import)
./scripts/load_data.sh

The script:

Skips if data already exists
Copies CSV files to Neo4j's import directory
Uses LOAD CSV for fast bulk import (10-50x faster than individual statements)
Also loads create_reference_data.cypher for instruments/techniques

Automatic Data Loading on Startup

The application can automatically load data sources when it starts. This runs in the background so the app remains responsive during loading. Data is only loaded if it doesn't already exist.

Configure in application.yml:

impromptu:
  data-loading:
    open-opus: true                                    # Load Open Opus composer/work catalog
    documents:                                         # Documents to ingest into RAG store
      - ./data/schumann/musicandmusician001815mbp.md
      - https://www.gutenberg.org/files/56208/56208-h/56208-h.htm

On first startup you'll see:

Starting background data loading...
Open Opus: loaded 220 composers, 24975 works, 10 epochs, 5 genres
Document: loaded musicandmusician001815mbp.md
Data loading complete: 2 loaded, 0 skipped, 0 failed

On subsequent startups, data that already exists is silently skipped (logged at DEBUG level).

Loading Open Opus Data (Manual)

The application can also load composer and works data from Open Opus manually via REST API.

Load into Neo4j (with the app running):

# Load data (fetches directly from Open Opus API)
curl -X POST http://localhost:8888/api/openopus/load

# Clear all Open Opus data
curl -X DELETE http://localhost:8888/api/openopus

This creates a normalized graph with:

Composer nodes linked to Epoch (Baroque, Romantic, etc.)
Work nodes linked to Genre (Orchestral, Chamber, Keyboard, etc.)
COMPOSED relationships connecting composers to their works

Example Cypher queries after loading:

// Find all Romantic composers
MATCH (c:Composer)-[:OF_EPOCH]->(e:Epoch {name: "Romantic"})
RETURN c.completeName

// Find all orchestral works by Brahms
MATCH (c:Composer {name: "Brahms"})-[:COMPOSED]->(w:Work)-[:OF_GENRE]->(g:Genre {name: "Orchestral"})
RETURN w.title

// Count works by genre
MATCH (w:Work)-[:OF_GENRE]->(g:Genre)
RETURN g.name, count(w) as works ORDER BY works DESC

Ingesting Documents (Manual)

Documents can also be ingested manually via REST API (in addition to automatic loading on startup).

Ingest a URL (e.g., Project Gutenberg):

curl -X POST "http://localhost:8888/api/documents/ingest?location=https://www.gutenberg.org/files/56208/56208-h/56208-h.htm"

Ingest a local file:

curl -X POST "http://localhost:8888/api/documents/ingest?location=./data/schumann/musicandmusician001815mbp.md"

Ingest all files in a directory:

curl -X POST "http://localhost:8888/api/documents/ingest-directory?path=./data"

Check store status:

curl http://localhost:8888/api/documents/info

Supported formats: .txt, .md, .html, .htm, .pdf, .docx, .doc, .rtf, .odt

Documents are parsed using Apache Tika, which extracts hierarchical structure (headings, sections) and chunks the content for embedding. The endpoint is idempotent - documents that already exist (by URI) are skipped.

Running the Web App

After Neo4j is running:

./mvnw spring-boot:run

The app runs on port 8888 (double the 88 piano keys) at http://127.0.0.1:8888/chat

A "Neo4j Browser" link in the footer opens the database UI with credentials pre-filled.

Important: Use 127.0.0.1 (loopback address), not localhost, for OAuth to work correctly with both Google and Spotify.

Google OAuth2 Authentication

The web interface supports Google OAuth2 for user authentication. To enable it:

Go to https://console.cloud.google.com/
Create a new project or select an existing one
Navigate to APIs & Services > Credentials
Create an OAuth client ID (Web application type)
Add authorized JavaScript origins: http://127.0.0.1:8888
Add authorized redirect URIs: http://127.0.0.1:8888/login/oauth2/code/google
Set environment variables with your credentials:

export GOOGLE_CLIENT_ID="your-client-id.apps.googleusercontent.com"
export GOOGLE_CLIENT_SECRET="your-client-secret"

Without these credentials, the app falls back to anonymous user mode.

Spotify Integration (Optional)

After logging in with Google, users can link their Spotify account to enable playlist management through the chatbot.

To enable Spotify integration:

Go to https://developer.spotify.com/dashboard
Create an app (or select existing)
Add redirect URI: http://127.0.0.1:8888/callback/spotify (loopback, not localhost)
In User Management, add your Spotify email as a user (required for development mode)
Set environment variables:

export SPOTIFY_CLIENT_ID="your-spotify-client-id"
export SPOTIFY_CLIENT_SECRET="your-spotify-client-secret"

Once configured, a "Link Spotify" button appears in the header after Google login. The chatbot can then:

List your Spotify playlists
Search for tracks
Create new playlists
Add tracks to playlists

Features

Pluggable Theme System: Multiple concert hall-inspired themes that users can switch between, with preferences persisted per user
Knowledge Base Panel: Collapsible panel showing extracted propositions from conversations
Real-time Chat: Streaming responses from the RAG-powered chatbot
User Authentication: Optional Google OAuth2 login
Spotify Integration: Link your Spotify account to create and manage playlists through the chatbot
Neo4j Browser: Direct link to explore the graph database

Themes

The application features a pluggable theme system inspired by famous concert halls and opera houses around the world. Themes are defined as CSS files in src/main/resources/themes/ and are automatically discovered at runtime.

Theme	Inspiration	Color Palette
Gold (default)	Classic concert hall	Gold accents on dark background
London	Royal Albert Hall	Deep blue with silver accents
Vienna	Musikverein	Imperial burgundy with cream
Midnight	Late-night recital	Deep purple with soft highlights
Bayreuth	Bayreuth Festspielhaus	Rich burgundy and wine red
Bastille	Opéra Bastille	Modern blue with clean lines
La Scala	Teatro alla Scala	Warm gold with Italian elegance
Concertgebouw	Royal Concertgebouw	Bold red with modern styling

Creating a Custom Theme:

Add a new CSS file to src/main/resources/themes/ with the theme metadata header:

/*
 * Theme: my-theme
 * Display Name: My Custom Theme
 * Description: A custom theme inspired by...
 * Default: false
 */

:root {
  --concert-black: #1a1a2e;
  --piano-black: #16213e;
  --accent-primary: #e94560;
  --accent-soft: #ff6b6b;
  --text-primary: #eaeaea;
  --text-secondary: #b8b8b8;
  /* ... additional CSS variables */
}

Themes override Lumo (Vaadin's design system) CSS variables, allowing deep customization of colors, typography, and component styling. User theme preferences are persisted in Neo4j and restored on login.

DICE REST API (Proposition Memory)

The application exposes DICE (Domain-Integrated Context Engineering) REST API endpoints for managing proposition-based memory. These endpoints are protected by API key authentication.

Enabling the REST Endpoints

To enable DICE REST endpoints in your application:

Import the configuration in your main application class:

import com.embabel.dice.web.rest.DiceRestConfiguration;
import org.springframework.context.annotation.Import;

@SpringBootApplication
@Import(DiceRestConfiguration.class)
public class MyApplication { }

Configure Spring Security to allow API key authentication (bypass OAuth/session auth):

@Override
public void configure(WebSecurity web) throws Exception {
    web.ignoring().requestMatchers("/api/v1/**");
    super.configure(web);
}

Add API key configuration to application.yml:

dice:
  security:
    api-key:
      enabled: true
      keys:
        - your-api-key-here

Provide a SchemaRegistry bean (see Schema Registry section below).

Authentication

All DICE endpoints require an API key header:

curl -H "X-API-Key: impromptu-admin" http://localhost:8888/api/v1/contexts/user123/memory

The default API key is impromptu-admin (configured in application.yml).

Extract Propositions from Text

# Extract propositions from text
curl -X POST http://localhost:8888/api/v1/contexts/alice_default/extract \
  -H "Content-Type: application/json" \
  -H "X-API-Key: impromptu-admin" \
  -d '{
    "text": "Johann Sebastian Bach composed the Brandenburg Concertos in 1721. He was born in Eisenach, Germany.",
    "sourceId": "music-facts"
  }'

Extract with User Association

Use knownEntities to associate extracted propositions with a user or other entities:

curl -X POST http://localhost:8888/api/v1/contexts/alice_default/extract \
  -H "Content-Type: application/json" \
  -H "X-API-Key: impromptu-admin" \
  -d '{
    "text": "I really enjoyed the Brahms Symphony No. 4 performance last night.",
    "sourceId": "user-conversation",
    "knownEntities": [
      {
        "id": "alice_id",
        "name": "Alice",
        "type": "User",
        "description": "A music enthusiast who loves classical music",
        "role": "The user in the conversation"
      }
    ]
  }'

The knownEntities array accepts entities with:

id - Unique identifier for the entity
name - Display name
type - Entity type label (e.g., "User", "Composer", "Work")
description - Optional description of the entity (defaults to name if not provided)
role - Descriptive role explaining context (e.g., "The user in the conversation", "A referenced composer")

Extract with Named Schema

If multiple schemas are registered, specify which one to use:

curl -X POST http://localhost:8888/api/v1/contexts/alice_default/extract \
  -H "Content-Type: application/json" \
  -H "X-API-Key: impromptu-admin" \
  -d '{
    "text": "The contract was signed on January 15, 2024.",
    "schemaName": "legal"
  }'

Extract Propositions from File

# Upload and process a document (PDF, Word, Markdown, HTML)
curl -X POST http://localhost:8888/api/v1/contexts/alice_default/extract/file \
  -H "X-API-Key: impromptu-admin" \
  -F "file=@./data/schumann/musicandmusician001815mbp.md" \
  -F "sourceId=schumann-writings"

# With schema name
curl -X POST http://localhost:8888/api/v1/contexts/alice_default/extract/file \
  -H "X-API-Key: impromptu-admin" \
  -F "file=@./document.pdf" \
  -F "schemaName=legal"

Query Memory

# Get all propositions for a context
curl -H "X-API-Key: impromptu-admin" \
  http://localhost:8888/api/v1/contexts/alice_default/memory

# Search by similarity
curl -X POST http://localhost:8888/api/v1/contexts/user123/memory/search \
  -H "Content-Type: application/json" \
  -H "X-API-Key: impromptu-admin" \
  -d '{
    "query": "What instruments did Bach play?",
    "topK": 5,
    "similarityThreshold": 0.7
  }'

# Get propositions about a specific entity
curl -H "X-API-Key: impromptu-admin" \
  "http://localhost:8888/api/v1/contexts/user123/memory/entity/bach-123"

Manage Propositions

# Get a specific proposition
curl -H "X-API-Key: impromptu-admin" \
  http://localhost:8888/api/v1/contexts/alice_default/memory/prop-456

# Delete a proposition (soft delete)
curl -X DELETE -H "X-API-Key: impromptu-admin" \
  http://localhost:8888/api/v1/contexts/alice_default/memory/prop-456

Configuration

The DICE API key security is configured in application.yml:

dice:
  security:
    api-key:
      enabled: true
      keys:
        - impromptu-admin          # Add your API keys here
      headerName: X-API-Key        # Optional, defaults to X-API-Key
      pathPatterns:                # Optional, defaults to /api/v1/**
        - /api/v1/**

Custom API Key Authenticator

For production, implement a custom ApiKeyAuthenticator bean to validate keys against a database or secrets manager. When you provide your own bean, the in-memory authenticator is automatically disabled:

@Component
public class DatabaseApiKeyAuthenticator implements ApiKeyAuthenticator {

    private final ApiKeyRepository apiKeyRepository;

    public DatabaseApiKeyAuthenticator(ApiKeyRepository apiKeyRepository) {
        this.apiKeyRepository = apiKeyRepository;
    }

    @Override
    public AuthResult authenticate(String apiKey) {
        return apiKeyRepository.findByKey(apiKey)
            .map(key -> new AuthResult.Authorized(
                key.getClientName(),
                Map.of("scopes", key.getScopes())
            ))
            .orElseGet(() -> new AuthResult.Unauthorized("Invalid API key"));
    }
}

The AuthResult.Authorized can include a principal name and metadata map, which are stored in request attributes for downstream use:

dice.auth.principal - The authenticated client identifier
dice.auth.metadata - Additional metadata (scopes, rate limits, etc.)

Schema Registry

To support multiple named schemas, provide a SchemaRegistry bean:

@Bean
SchemaRegistry schemaRegistry(DataDictionary defaultSchema) {
    InMemorySchemaRegistry registry = InMemorySchemaRegistry.withDefault(defaultSchema);
    registry.register("music", DataDictionary.fromClasses(Composer.class, Work.class));
    registry.register("legal", DataDictionary.fromClasses(Contract.class, Party.class));
    return registry;
}

If no SchemaRegistry bean is provided, wrap your default DataDictionary with InMemorySchemaRegistry.withDefault(schema).

Implementation Details

Neo4j Vector Storage

The application uses Neo4j as its vector store for RAG, configured via application.yml:

database:
  datasources:
    neo:
      type: NEO4J
      host: ${NEO4J_HOST:localhost}
      port: ${NEO4J_PORT:7888}
      user-name: ${NEO4J_USERNAME:neo4j}
      password: ${NEO4J_PASSWORD:brahmsian}
      database-name: ${NEO4J_DATABASE:neo4j}

neo4j:
  http:
    port: ${NEO4J_HTTP_PORT:8889}

Key aspects:

Neo4j with vector indexes: Chunks are stored as nodes with vector embeddings for similarity search
Graph relationships: Content relationships can be modeled as edges in the graph
Persistent storage: Data survives container restarts (stored in Docker volume)
Configurable chunking: Content is split into chunks with configurable size (default 800 chars) and overlap (default 100 chars)
Admin queries: See cypher/admin.cypher for useful queries to inspect and manage the database

Chunking properties can be configured via application.yml:

impromptu:
  neo-rag:
    max-chunk-size: 800
    overlap-size: 100

Chatbot Creation

The chatbot is created in ChatConfiguration.java:

@Bean
Chatbot chatbot(AgentPlatform agentPlatform) {
    return AgentProcessChatbot.utilityFromPlatform(agentPlatform);
}

The AgentProcessChatbot.utilityFromPlatform() method creates a chatbot that automatically discovers all @Action methods in @EmbabelComponent classes. Any action with a matching trigger becomes eligible to be called when appropriate messages arrive.

Action Handling

Chat actions are defined in ChatActions.java:

@EmbabelComponent
public class ChatActions {

    private final ToolishRag toolishRag;
    private final ImpromptuProperties properties;
    private final SpotifyService spotifyService;

    public ChatActions(
            SearchOperations searchOperations,
            SpotifyService spotifyService,
            ApplicationEventPublisher eventPublisher,
            ImpromptuProperties properties) {
        this.toolishRag = new ToolishRag(
                "sources",
                "The music criticism written by Robert Schumann: His own writings",
                searchOperations)
                .withHint(TryHyDE.usingConversationContext());
        this.spotifyService = spotifyService;
        this.properties = properties;
    }

    @Action(canRerun = true, trigger = UserMessage.class)
    void respond(Conversation conversation, ImpromptuUser user, ActionContext context) {
        List<Object> tools = new LinkedList<>();
        if (user.isSpotifyLinked()) {
            tools.add(new SpotifyTools(user, spotifyService));
        }
        var assistantMessage = context.ai()
                .withLlm(properties.chatLlm())
                .withPromptContributor(user)
                .withReference(toolishRag)
                .withToolObjects(tools)
                .withTemplate("ragbot")
                .respondWithSystemPrompt(conversation, Map.of(
                        "properties", properties,
                        "user", user
                ));
        context.sendMessage(conversation.addMessage(assistantMessage));
    }
}

Key concepts:

@EmbabelComponent: Marks the class as containing agent actions that can be discovered by the platform
@Action annotation:
- trigger = UserMessage.class: This action is invoked whenever a UserMessage is received in the conversation
- canRerun = true: The action can be executed multiple times (for each user message)
ToolishRag as LLM reference:
- Wraps the SearchOperations (Neo4j vector store) as a tool the LLM can use
- When .withReference(toolishRag) is called, the LLM can search the RAG store to find relevant content
- The LLM decides when to use this tool based on the user's question
Spotify tools: When the user has linked their Spotify account, SpotifyTools is added as a tool object, enabling playlist management

Prompt Templates

Chatbot prompts are managed using Jinja templates rather than inline strings. This is best practice for chatbots because:

Prompts grow complex: Chatbots require detailed system prompts covering persona, guardrails, objectives, and behavior guidelines
Separation of concerns: Prompt engineering can evolve independently from Java code
Reusability: Common elements (guardrails, personas) can be shared across different chatbot configurations
Configuration-driven: Switch personas or objectives via application.yml without code changes

Separating Voice from Objective

The template system separates two concerns:

Objective: What the chatbot should accomplish - the task-specific instructions and domain expertise
Voice: How the chatbot should communicate - the persona, tone, and style of responses

This separation allows mixing and matching. You could have a "music" objective answered in the voice of Shakespeare or a different persona without duplicating instructions.

Template Structure

src/main/resources/prompts/
├── ragbot.jinja                    # Main template entry point
├── elements/
│   ├── guardrails.jinja            # Safety and content restrictions
│   └── personalization.jinja       # Dynamic persona/objective loader
├── personas/                       # HOW to communicate (voice/style)
│   ├── impromptu.jinja             # Default: friendly music guide
│   ├── shakespeare.jinja           # Elizabethan style
│   ├── bible.jinja                 # Biblical style
│   ├── adaptive.jinja              # Adapts to user
│   └── jesse.jinja                 # Casual style
└── objectives/                     # WHAT to accomplish (task/domain)
    ├── music.jinja                 # Classical music education (default)
    └── legal.jinja                 # Legal document analysis

How Templates Are Loaded

The main template ragbot.jinja composes the system prompt from reusable elements:

{% include "elements/guardrails.jinja" %}

{% include "elements/personalization.jinja" %}

Keep your responses under {{ properties.voice().maxWords() }} words unless they
MUST be longer for a detailed response or quoting content.

The personalization.jinja template dynamically includes persona and objective based on configuration:

{% set persona_template = "personas/" ~ voice.persona() ~ ".jinja" %}
{% include persona_template %}

{% set objective_template = "objectives/" ~ objective ~ ".jinja" %}
{% include objective_template %}

Configuration Reference

All configuration is externalized in application.yml, allowing behavior changes without code modifications.

application.yml Reference

database:
  datasources:
    neo:
      host: localhost
      port: 7888               # Neo4j Bolt port
      user-name: neo4j
      password: brahmsian

neo4j:
  http:
    port: 8889                 # Neo4j Browser HTTP port

impromptu:
  # RAG chunking settings
  neo-rag:
    max-chunk-size: 800        # Maximum characters per chunk
    overlap-size: 100          # Overlap between chunks for context continuity

  # LLM model selection and hyperparameters
  chat-llm:
    model: gpt-4.1-mini        # Model to use for chat responses
    temperature: 0.0           # 0.0 = deterministic, higher = more creative

  # Voice controls HOW the chatbot communicates
  voice:
    persona: impromptu         # Which persona template to use (personas/*.jinja)
    max-words: 250             # Hint for response length

  # Objective controls WHAT the chatbot accomplishes
  objective: music             # Which objective template to use (objectives/*.jinja)

embabel:
  models:
    default-llm:
      model: gpt-4.1-mini
    default-embedding-model:
      model: text-embedding-3-small

Switching Personas

To change the chatbot's personality, simply update the persona value:

impromptu:
  voice:
    persona: shakespeare     # Now responds in Elizabethan English

To use a different LLM:

impromptu:
  chat-llm:
    model: gpt-4.1           # Use the larger GPT-4.1 model
    temperature: 0.7         # More creative responses

No code changes required - just restart the application.

Development Notes

Integration Tests (`*IT.java`)

Tests with the IT suffix (e.g., RjIngestionIT.java) are not executed by CI. These are integration tests designed for developers to run locally against a real LLM and Neo4j database.

Key characteristics:

Real LLM calls: These tests make actual API calls to OpenAI/Anthropic, requiring valid API keys
Real database: Tests run against the local Neo4j instance started via Docker Compose
Transactional rollback: Tests use Spring's @Transactional annotation to automatically roll back all database changes after each test, leaving the database in its original state
Excluded from CI: The Maven Surefire plugin is configured to exclude *IT.java files and tests tagged with @Tag("integration")

Running integration tests locally:

# Ensure Neo4j is running
docker compose up -d

# Run a specific integration test
./mvnw test -Dtest=RjIngestionIT

# Run all integration tests (requires API keys)
./mvnw test -DexcludedGroups= -Dtest="**/*IT"

Example integration test structure:

@SpringBootTest
@Transactional  // Rolls back all changes after each test
@Tag("integration")
class MyFeatureIT {

    @Autowired
    private SomeService service;

    @Test
    void testWithRealLlm() {
        // This test calls real APIs and writes to Neo4j
        // All database changes are rolled back automatically
    }
}

This pattern allows developers to test against real infrastructure while keeping the database clean for subsequent test runs.

Composer Enhancement Pipeline

The application includes a pipeline for enriching composer data using LLM-generated content. Each enhancer generates a CSV file that can be reviewed and curated by musicologists before loading into Neo4j.

Available Enhancers

Enhancer	CSV Location	Description
Influences	`data/influences/composer-influences.csv`	INFLUENCED relationships between composers (e.g., Beethoven → Brahms)
Techniques	`data/enhancements/composer-techniques.csv`	USES relationships linking composers to compositional techniques
Nationalities	`data/enhancements/composer-nationalities.csv`	HAS_NATIONALITY relationships linking composers to countries

Workflow

All enhancers follow the same generate → review → apply workflow:

Generate: LLM analyzes composers and generates candidate data with confidence scores
Review: A musicologist reviews the CSV, changing status from pending to approved for valid entries
Apply: Approved rows are loaded into Neo4j via the UI or REST API

Musicologist Review Process

All generated CSV files are designed to be reviewed and curated by musicologists:

Generate CSVs: Use the UI (Enhancers panel) or REST API to generate candidate data
Open in Spreadsheet: Edit CSVs in Excel, Numbers, Google Sheets, or any spreadsheet application
Review Each Row:
- Verify the data is historically/factually accurate
- Adjust confidence and other values as needed
- Change status from pending to approved for valid entries
- Delete rows that are incorrect or speculative
Save and Commit: Save the CSV files and commit to version control
Apply: Use the UI or REST API to load approved data into Neo4j

The CSV files are the source of truth and can be iteratively refined over time.

REST API

# List all enhancers
curl http://localhost:8888/api/enhancers

# Generate CSV for a specific enhancer
curl -X POST http://localhost:8888/api/enhancers/influences/generate
curl -X POST http://localhost:8888/api/enhancers/techniques/generate
curl -X POST http://localhost:8888/api/enhancers/nationalities/generate

# Generate all CSVs
curl -X POST http://localhost:8888/api/enhancers/generate-all

# Apply CSV for a specific enhancer
curl -X POST http://localhost:8888/api/enhancers/influences/apply

# Apply all CSVs (respects status field - only loads 'approved' rows)
curl -X POST http://localhost:8888/api/enhancers/apply-all

# Force apply all CSVs (ignores status field - loads all rows)
curl -X POST http://localhost:8888/api/enhancers/apply-all?force=true

Influences CSV Format

The influences CSV (data/influences/composer-influences.csv) has these columns:

Column	Description
`from`	Composer ID who did the influencing (e.g., `ludwig-van-beethoven-1770`)
`to`	Composer ID who was influenced (e.g., `johannes-brahms-1833`)
`reason`	Brief explanation of the influence relationship
`strength`	0.0-1.0 indicating how significant the influence was
`confidence`	0.0-1.0 indicating how certain the relationship is documented
`divergence`	0.0-1.0 indicating how much the influenced composer diverged stylistically
`status`	`pending` (generated) or `approved` (ready to load)

Legacy Influences API

The original influences-specific endpoints are still available:

curl -X POST http://localhost:8888/api/influences/generate
curl -X POST http://localhost:8888/api/influences/load
curl http://localhost:8888/api/influences/stats
curl http://localhost:8888/api/influences/composers

Miscellaneous

Killing a Stuck Server Process

If your IDE dies or the server doesn't shut down cleanly, you may need to manually kill the process on port 8888:

lsof -ti :8888 | xargs kill -9

Name		Name	Last commit message	Last commit date
Latest commit History 171 Commits
.github		.github
.mvn/wrapper		.mvn/wrapper
.vscode		.vscode
cypher		cypher
data		data
docs		docs
images		images
scripts		scripts
src		src
.gitignore		.gitignore
CODE_OF_CONDUCT.md		CODE_OF_CONDUCT.md
LICENSE		LICENSE
README.md		README.md
docker-compose.yml		docker-compose.yml
mvnw		mvnw
mvnw.cmd		mvnw.cmd
pom.xml		pom.xml
vite.config.ts		vite.config.ts

License

embabel/impromptu

Folders and files

Latest commit

History

Repository files navigation
