OpenGL Simulations

A Repository of Real-time Simulations: GPU fluid simulation (2D/3D), Collision Detection, Rubiks Cube Solver, Cube Marching and Procedural Geometry.

Table of Contents

• Overview
• Features
• Prerequisites
• Build (Windows)
• Run the programs
• Controls
• Project structure
• Performance notes
• Troubleshooting
• License

Overview

This suite projects that implement multiple simulation systems with modern OpenGL (core profile) and compute shaders for GPU-accelerated algorithms and physics. It includes SPH-based fluid simulation (2D/3D), a determimnistic multithreaded particle collision system, a rubiks cube solver visualization, cube marching visualization and a small set of procedural geometry tools.

Features

• GPU Fluid Simulation (2D/3D) using SPH + spatial hashing
• Deterministic Particle Collision System with uniform grid partitioning and multithreading
• Rubiks Cube solver using Thistlethwaite's Algorithm
• Marching Cube and Signed Distance Function algorithms
• Procedural geometry: parametric surfaces, polygons, spheres, and helpers
• Modern OpenGL 3.3+ rendering, OpenGL 4.3+ compute shaders
• GLM math, GLFW windowing/input, GLAD loader, optional Assimp model loading

Prerequisites

• Windows 10/11 with a GPU that supports OpenGL 3.3 (4.3+ recommended for compute shaders).
• CMake 3.15 or newer (3.27+ recommended).
• Visual Studio 2019/2022 with the Desktop development with C++ workload (or the MSVC Build Tools + Ninja).
• PowerShell 7+ or Windows Terminal for running the build commands.
• Git (optional, but recommended for pulling updates).
• Internet access on the first configure so CMake can download third-party libraries.

Dependency management (automatic)

1. Clone the repository: git clone https://github.com/Programmer-5090/Simulations-OpenGL.git
2. Configure the project: cmake -B build -S . -G "Visual Studio 17 2022" -A x64
3. During the first configure CMake will fetch/build:
   • GLFW 3.4
   • GLAD (OpenGL loader)
   • GLM 1.0
   • Assimp 5.3 (compiled statically)
   • SFML audio/system modules (for Rubik’s Cube + audio tests)
   • stb_image.h
4. Dependencies are cached inside build/_deps. Subsequent configures reuse the downloads; delete build/_deps if you ever want to force a refresh.
5. If you must build offline, run the configure step once while online and archive build/_deps for reuse.

Program details and configs

All paths are relative to the repo root.

1. GPUFluidSim 2D

• OpenGL context: 4.3 Core (compute shaders)
• Window: 1200 x 800
• Default particles: 10,000
• Shaders: SPHFluid/shaders/FluidSim-2D.compute, SPHFluid/shaders/particle2d.vs, SPHFluid/shaders/particle2d.fs
• World bounds: x=[-10, 10], y=[-6.67, 6.67]

2. GPUFluidSim 3D

• OpenGL context: 4.3 Core (compute shaders)
• Window: 1280 x 720
• Default particles: 10,000
• Shaders: SPHFluid/shaders/FluidSim-3D.compute, SPHFluid/shaders/particle3d.vs, SPHFluid/shaders/particle3d.fs, SPHFluid/shaders/box.*, shaders/infinite_grid.*
• Simulation bounds: axis‑aligned box of size 4 x 4 x 4

3. CollisionSystem (2D)

• OpenGL context: 3.3 Core
• Window title: 1280 x 800 (Resizable)
• Auto‑spawning streams from the left edge; performance‑aware throttling

4. RubiksCube + solver tests

• RubiksCube is the interactive viewer/solver.
• RubiksStateTest and RubiksSolverTest are headless executables that validate cube IDs and solver heuristics.

5. MarchingTest (CPU/GPU marching cubes)

• Visualizes marching cubes tables on the CPU for quick experimentation.
• Targets: MarchingTest, testGPU, testCPUBunny (each with its own executable in output/<Name>/<Config>/).

6. debugBVH

• Standalone viewer for the BVH structures generated by the marching cubes experiments.
• Useful when tuning subdivision or debugging occupancy issues.

7. OpenGLProject

• OpenGL context: 3.3 Core
• Demonstrates geometry and basic rendering with an infinite grid
• Shaders: shaders/vertex.vs, shaders/simple_fragment.fs, shaders/infinite_grid.*, optional normal debug shaders/normal_debug.*

8. AudioTest

• Minimal SFML audio harness that plays the bundled audio/beep.wav to confirm your audio device/driver setup.

Build (Windows)

Everything is driven by plain CMake commands, so any terminal (VS Developer Prompt, PowerShell, etc.) works the same way. Dependencies download automatically into build/_deps during the first configure step.

1. Configure the project (generator/arch optional):

cmake -B build -S . -G "Visual Studio 17 2022" -A x64

2. Build all targets in Debug:

cmake --build build --config Debug

3. Build Release (recommended for demos):

cmake --build build --config Release

4. Build a specific target/variant (example for debugBVH Release):

cmake --build build --config Release --target debugBVH

Executables land under output/<TargetName>/<Config>/ (for example output/OpenGLProject/Debug/OpenGLProject.exe), so each folder is self-contained. A Visual Studio solution is still generated at build/OpenGLProject.sln if you prefer opening it directly in VS.

Run the programs

After a build, each executable lives in output/<Target>/<Config>/. Launch them straight from PowerShell or CMD; swap Release for Debug as needed.

Primary demos:

• GPUFluidSim 2D: .\output\GPUFluidSim2D\Release\GPUFluidSim2D.exe
• GPUFluidSim 3D: .\output\GPUFluidSim3D\Release\GPUFluidSim3D.exe
• Collision System: .\output\CollisionSystem\Release\CollisionSystem.exe
• OpenGL Project: .\output\OpenGLProject\Release\OpenGLProject.exe
• Rubik's Solver: .\output\OpenGLProject\Release\RubiksCube.exe

Additional demos/tests:

• Marching cubes: .\output\MarchingTest\<Config>\MarchingTest.exe, testGPU.exe, testCPUBunny.exe
• debugBVH viewer: .\output\debugBVH\<Config>\debugBVH.exe
• Rubik's Test suite: RubiksStateTest.exe, RubiksSolverTest.exe
• Audio Test: .\output\AudioTest\<Config>\AudioTest.exe

For quick one-offs you can also build and run a single target via CMake:

cmake --build build --config Release --target GPUFluidSim3D
.\output\GPUFluidSim3D\Release\GPUFluidSim3D.exe

Shareable bundles

Each executable now has an isolated runtime folder under output/<Target>/<Config>/ that contains the binary, required DLLs, and only the assets it truly needs (for example, RubiksCube ships just its two shader pairs plus the single cube texture and solver tables). Zip that directory to share a standalone build of that specific program.

Note on shader paths: executables load shaders relative to the repo root (e.g., SPHFluid/shaders/...). Make sure your current directory is the project root before launching a binary.

Controls

GPU Fluid Simulation (2D)

• Mouse move: interact with the fluid
• Left mouse: attract particles
• Right mouse: repel particles
• Space: pause/resume
• R: reset simulation
• ESC: exit

GPU Fluid Simulation (3D)

• Mouse look and scroll wheel: orbit/zoom the camera
• WASD: move horizontally
• Shift: move down
• C: move up
• Space: pause/resume
• R: reset simulation
• ESC: exit

Collision System (2D)

• Auto‑spawning particle streams from the left edge
• C: clear all particles
• Space: move on to phase 3
• K: switch images
• ESC: exit

RubiksCube viewer (interactive solver)

• Left mouse: select a cubie via raycast; hold middle mouse to orbit, mouse wheel to zoom
• Arrow keys: rotate the face that contains the current selection (mapped to camera orientation)
• Number keys 1‑6: trigger a single U, D, R, L, F, or B quarter turn while idle
• P: scramble ~50 random moves · O: launch the solver queue · G: toggle debug face colors · T: toggle textured stickers
• ESC: exit (RubiksStateTest and RubiksSolverTest are headless and print to the console only)

MarchingTest (stepwise CPU marching cubes)

• Mouse look + scroll: move the camera; WASD to translate, C to move up, Left Shift to move down
• N or Right Arrow: process exactly one grid cell
• Space: toggle automatic stepping · G: generate the full mesh once · C: clear mesh/reset stepping
• H: toggle normal visualization · B: toggle chunk bounding box · F: toggle wireframe rendering
• ESC: exit

testGPU (GPU Marching Cubes)

• Mouse look + scroll for camera control; WASD, C (up), Left Shift (down) translate the camera
• B: toggle BVH bounding boxes · M: toggle the marched mesh visibility
• ESC: exit

testCPUBunny (CPU Marching Cubes)

• Mouse look + scroll, WASD movement, C up, Left Shift down
• ESC: exit

debugBVH

• Mouse look + scroll, WASD movement, C up, Left Shift down
• B: toggle BVH boxes · M: toggle bunny mesh visibility
• Up/Down arrows: change which BVH depth level is rendered
• Left/Right arrows: change maximum BVH construction depth (rebuilds the tree)
• ESC: exit

OpenGLProject demo

• Mouse look + scroll to control the free camera
• WASD: move horizontally · C: move up · Left Shift: move down
• ESC: exit

AudioTest

• Console‑only harness that plays several beep variations automatically; close the console or hit Ctrl+C to stop early

Project structure

├── SPHFluid/             # Fluid simulation (2D/3D) and compute shaders
│   ├── 2D/
│   ├── 3D/
│   └── shaders/
├── Collision System/     # Particle collision detection
├── Rubiks/               # Rubiks cube solver and tests
├── Marching Cubes        # Marching cube algorithm on CPU and GPU
├── geometry/             # Procedural geometry and helpers
├── shaders/              # Vertex/fragment shaders
├── models/               # Assets for demos
├── build/                # CMake build tree (generated)
└── output/               # Built executables (Debug/Release)

Performance notes

• 2D particles: 10k - 15k+ depending on GPU and Window size at 144fps
• 3D particles: 50k - 60k+ at 50 - 60fps
• Collsion System: 15k+ particles at 60fps
• Rubiks Cube Solver: 45 moves or less to solve
• Memory: ~100–200 MB for common presets
• Dedicated GPU strongly recommended for 3D + compute

Troubleshooting

Black screen or no motion:

• Verify GPU and drivers support OpenGL 4.3+ for compute shaders
• Try the Release build for performance-sensitive paths

Slow performance:

• Reduce particle count and grid resolution in the simulation

Build errors on Windows:

• Ensure CMake and Visual Studio are installed and on PATH
• Use the provided VS Code tasks to avoid environment conflicts

Missing DLLs:

• Visual C++ Redistributable may be required for some systems

Gallery

GPU Fluid Simulation 2D

GPU Fluid Simulation 3D

Collision System

Marching Cubes & BVH Debugging

Rubik's Cube Solver

Sources

SPH Techniques for the Physics Based Simulation of Fluids and Solids

Foundations of SPH

Nihaljn Marching Cubes

Signed Distance Function

Jaapsch Rubik's Solver Blog

License

This project is provided for educational and research purposes. Third‑party libraries retain their respective licenses.
